ModWood Xtreme Guard
ModWoodComposite
From $155 per m² across Australia, inc GST
$118.04 per 5.4 m board
Set your state
5 colours: pick one to see it
- Board size
- 137 × 23 mm5.4 m lengths
- Cap
- Capped 4 sidesA tougher outer shell that resists stains and fading
- Core
- Not published
- Fixing
- Hidden clips or face screwsKlevaKlip Snap-LOC KSL137N (grooved boards)
- Warranty
- 25 years, residentialFade and stain: 25 years
- Joist centres
- 450 mm maxResidential; 450 mm commercial
Recommended Recommended and featured on the deck designer. Design with this board
Why we recommend it
Composite Decks picks these ranges: they are the boards we know well, and the deck designer is built around them. No brand or seller pays for the place. Every other range we track is listed below them in the usual order.
Colours (5)
Photos are the maker’s, credited. Render colours are sampled from the maker’s swatch images and are indicative only: order a sample before you choose.
Specifications
Every published fact, with its source and the day it was checked.
- capclip groove13723
Deck board 137 × 23 mm · 5.4 m, drawn with core not stated, capped on every face, grooved on both edges for hidden clips
- 13723
Deck board 137 × 23 mm · 5.4 m, drawn with core not stated, capped on every face, square edges
The board
| Fact | Published value | Source · checked |
|---|---|---|
| Material | Wood-plastic composite | Maker’s datasheet · checked |
| Cap | Capped on all four sides | Maker’s datasheet · checked |
| Deck board | 137 × 23 mm, grooved both edges · 5.4 m lengths | Maker’s datasheet · checked |
| Weight (137 × 23) | 3.6 kg per metre How this was readkg/lm from the August 2026 brochure fixing-specification table. | Maker’s datasheet · checked |
| Deck board | 137 × 23 mm, square edges · 5.4 m lengths | Maker’s datasheet · checked |
| Weight (137 × 23) | 3.6 kg per metre How this was readkg/lm from the August 2026 brochure fixing-specification table. | Maker’s datasheet · checked |
| Made in | Australia How this was readQ&A: made in Melbourne, Australia. | Maker’s datasheet · checked |
Installation
| Fact | Published value | Source · checked |
|---|---|---|
| Max joist centres, residential | 450 mm | Maker’s install guide · checked |
| Max joist centres, commercial | 450 mm How this was readSame printed maximum; "suitability for commercial applications: yes" but centres may be reduced depending on concentrated load - contact ModWood for deflection calculation. | Maker’s install guide · checked |
| Gap between boards | 4 mm | Maker’s install guide · checked |
| End gap rule | Butt joins 2 mm · To walls and solid structures 6 mm · Fix when ambient is below 25 C; do not leave boards in full sun before fixing (board temperature 20-30 C above ambient) - boards "grow" lengthways and butt gaps open once they normalise. | Maker’s install guide · checked |
| Butt joints | Board ends share a single joist | Maker’s install guide · checked |
| Minimum clearance under the boards | 150 mm How this was readPerimeter ventilation mandatory (do not seal deck ends with garden beds, trees or solid objects). Lower ground clearance than the uncapped ranges (300 mm). (also: over concrete 50 mm) | Maker’s install guide · checked |
| Subframes | timber and steel | Maker’s install guide · checked |
| Fixing: hidden clip | KlevaKlip Snap-LOC KSL137N (grooved boards) | Maker’s install guide · checked |
| Fixing: face screw | ModWood colour-coated head screws for square-edge… How this was readModWood colour-coated head screws for square-edge starter boards and irregular shapes: timber T-20 10-gauge x 65 mm stainless 305/316 (August 2026 brochure; the 2019 brochure listed 10-gauge x 50 mm); steel T-20 10-gauge x 40 mm stainless 410 (penetrates up to 4 mm wall) | Maker’s install guide · checked |
| Installation guide | Maker’s install guide · checked |
Tested performance
| Fact | Published value | Source · checked |
|---|---|---|
| Bushfire attack level (AS 3959) | No BAL rating stated How this was readOnly Flame Shield may be used in BAL-rated zones; non-flame-retardant boards must not be used in BAL zones. | Maker’s datasheet · checked |
| Slip resistance (AS 4586) | P5 (wet pendulum) | Maker’s datasheet · checked |
Warranty
| Fact | Published value | Source · checked |
|---|---|---|
| Warranty, residential | 25 years How this was readLimited durability warranty (rot, warp, crack, split, splinter, termite damage, material defects). Residential = individual residence. Claims in years 11-25 are prorated (south of the Tropic of Capricorn 80/60/40/20/10%; north 50/25/10/5/5%). Transferable once within 5 years of purchase; Australia only; fasteners not supplied by ModWood are not covered; Low-E glass heat damage excluded. | Maker’s warranty · checked |
| Warranty, commercial | 10 years How this was readCommercial = any installation other than on an individual residence; 10 years, not prorated per the schedule shown (schedule applies to residential years 11-25). | Maker’s warranty · checked |
| Fade and stain warranty | 25 years How this was readResidential only. Fade: colour change of more than 5 Delta E (CIE) units. Stain: permanent staining from food/beverage spills or mould/mildew only if removed with soap/water or mild cleaner within 72 hours; must try cleaning then professional cleaning (claim within 30 days). Same prorated schedule as s6. Painted/coated boards void it. | Maker’s warranty · checked |
Other published facts (2)
Other published facts
| Fact | Published value | Source · checked |
|---|---|---|
| Recycled content (as published) | 90% recycled materials | Maker’s web page · checked |
| Fixing notes (as published) | notes: Pack sizes 100 and 350 (timber), 100 (steel). 4 mm packer under the face-fixed starter board. Do not use an impact driver. Cannot be installed over existing decking boards. | Maker’s install guide · checked |
Every fact here carries its source and the day it was checked. Documents opened 6 Oct 2026.
Prices by state
Set your state once and every price on this site is quoted for it, including GST. Then this page shows the ModWood Xtreme Guard prices in your state: each the average of the sellers we track there.
ModWood Xtreme Guard: national averages, across Australia
| Board size | Average $/m² | Per board | Sellers | Prices to |
|---|---|---|---|---|
| ModWood Xtreme Guard 137 × 23, grooved | $155.03 | $118.04 / 5.4 m | 8 | |
| ModWood Xtreme Guard 137 × 23, square edge | $159.87 | $121.73 / 5.4 m | 4 |
Prices from 8 sellers across Australia. We don’t list the whole market, so other sellers may have different prices. Seen 14–15 Oct 2026.
Prices include GST. Each is the average of the sellers we track for that board, each seller counted once, with any price more than 25% from the middle one left out; sample data is badged.
How we get these prices
Each price is an average of the retail prices we have seen for that board, with any price more than 25% above or below the middle price left out. Each seller counts once. Prices include GST and are per square metre of deck (the board’s cover width plus the gap beside it) and per board. Prices were seen on the dates shown on sellers’ own price lists and websites; confirm with the seller before you buy. 2 sellers’ prices were left out as more than 25% from the middle one.
Per lineal metre: ModWood Xtreme Guard 137 × 23, grooved average $21.86 · ModWood Xtreme Guard 137 × 23, square edge average $22.54.
Customer reviews
Write a review of Xtreme Guard
We publish every review that meets our review policy, positive or negative. Labels show when a reviewer was invited, got something for writing it, or works in the industry.
No reviews yet. Be the first to review it.
Documents
The maker’s own documents, linked where they publish them (never re-hosted).
- Installation guideModWood XTREME GUARD - Fixing Instructions (September 2020)
- WarrantyModWood XTREME GUARD Limited Domestic/Commercial Warranty
- WarrantyModWood XTREME GUARD Limited Residential Fade and Stain Warranty
- DatasheetModWood XTREME GUARD bulletin: how to identify the correct face (November 2019)
All 10 sources behind this page
- ModWood product brochure (August 2026) incl. fixing-specification table and ITI distributor list
- CodeMark Certificate of Conformity CM70175 Rev2 - ModWood Decking (issued 31 Jul 2025, revalidated 10 Jun 2026, expires 31 Jul 2028)
- ModWood XTREME GUARD - Fixing Instructions (September 2020)
- ModWood XTREME GUARD Limited Domestic/Commercial Warranty
- ModWood XTREME GUARD Limited Residential Fade and Stain Warranty
- ModWood XTREME GUARD bulletin: how to identify the correct face (November 2019)
- Questions and Answers on ModWood (November 2025)
- ModWood - Xtreme Guard product page
- NEW CAPPED XTREME GUARD brochure (October 2019 edition); copy hosted by Bendigo Timber
- ModWood - Colour range page (swatches)
Facts are taken from the highest-ranked source (certificates and test reports, then install guides and datasheets, then warranties, then web pages); when sources disagree the specification says so, and safety facts take the conservative value. Every plan the designer draws from these figures is a concept plan, not for construction: the span tables behind its framing have been checked by a structural engineer, but a builder, building surveyor or certifier must check the plan before you build.
